GitOps CI/CD with ArgoCD, EKS, Terraform, and Helm

By Tech Career Hubs

Published On:

Project: GitOps CI/CD with ArgoCD, EKS, Terraform, and Helm

Table of Contents

  1. Project Overview & Architecture

  2. Prerequisites

  3. Provisioning EKS with Terraform

  4. Setting Up Your Git Repositories

  5. Installing and Configuring ArgoCD

  6. Deploying a Sample Application with Helm & ArgoCD

  7. Managing Secrets with External Secrets Operator

  8. Canary Deployments with Argo Rollouts

  9. Putting It All Together: The CI Pipeline (GitHub Actions)

  10. Tearing Down the Infrastructure

1. Project Overview & Architecture

We will build a complete GitOps workflow. The key idea is that Git is the single source of truth.

  • Developers push new application code to the app-source-code repository.

  • A CI Pipeline (GitHub Actions) builds a new Docker image, pushes it to a registry (AWS ECR), and then updates a Helm chart’s values.yaml in the manifests-repo with the new image tag.

  • ArgoCD, running in our EKS cluster, constantly monitors the manifests-repo.

  • When ArgoCD detects the change (the new image tag), it automatically pulls the updated manifests and applies them to the Kubernetes cluster, deploying the new version of the application.

2. Prerequisites

  1. AWS Account with programmatic access (Access Key & Secret Key).

  2. AWS CLI installed and configured (aws configure).

  3. Terraform installed (>= 1.0).

  4. kubectl installed.

  5. Helm installed.

  6. GitHub Account.

  7. Docker installed and running locally (for the CI part).

3. Provisioning EKS with Terraform

We will use Terraform to create the VPC, EKS cluster, and an ECR repository for our Docker images.

Directory Structure:

GitOps CI/CD
└── terraform/
    ├── main.tf
    ├── variables.tf
    ├── vpc.tf
    ├── eks.tf
    └── outputs.tf

terraform/variables.tf

variable "aws_region" {
  description = "The AWS region to deploy resources in."
  type        = string
  default     = "us-east-1"
}

variable "cluster_name" {
  description = "The name for the EKS cluster."
  type        = string
  default     = "gitops-cluster"
}

variable "app_name" {
  description = "The name of our sample application."
  type        = string
  default     = "guestbook"
}

terraform/main.tf

provider "aws" {
region = var.aws_region
access_key = "your access key"
secret_key = "your secret key"
}

# Create an ECR repository to store our application's Docker image
resource "aws_ecr_repository" "app_ecr_repo" {
  name                 = "${var.app_name}-repo"
  image_tag_mutability = "MUTABLE"

  image_scanning_configuration {
    scan_on_push = true
  }
}

terraform/vpc.tf

We use the official AWS VPC module for simplicity and best practices.

module "vpc" {
  source  = "terraform-aws-modules/vpc/aws"
  version = "5.1.2"

  name = "${var.cluster_name}-vpc"
  cidr = "10.0.0.0/16"

  azs             = ["${var.aws_region}a", "${var.aws_region}b", "${var.aws_region}c"]
  private_subnets = ["10.0.1.0/24", "10.0.2.0/24", "10.0.3.0/24"]
  public_subnets  = ["10.0.101.0/24", "10.0.102.0/24", "10.0.103.0/24"]

  enable_nat_gateway   = true
  single_nat_gateway   = true
  enable_dns_hostnames = true

  public_subnet_tags = {
    "kubernetes.io/cluster/${var.cluster_name}" = "shared"
    "kubernetes.io/role/elb"                  = "1"
  }

  private_subnet_tags = {
    "kubernetes.io/cluster/${var.cluster_name}" = "shared"
    "kubernetes.io/role/internal-elb"         = "1"
  }
}

terraform/eks.tf

We use the official AWS EKS module.

module "eks" {
  source  = "terraform-aws-modules/eks/aws"
  version = "19.16.0"

  cluster_name    = var.cluster_name
  cluster_version = "1.28"

  vpc_id     = module.vpc.vpc_id
  subnet_ids = module.vpc.private_subnets

  eks_managed_node_group_defaults = {
    ami_type = "AL2_x86_64"
  }

  eks_managed_node_groups = {
    one = {
      name           = "general-nodes"
      instance_types = ["t3.medium"]
      min_size       = 1
      max_size       = 3
      desired_size   = 2
    }
  }
}

terraform/outputs.tf

output "cluster_name" {
  description = "Amazon EKS Cluster name"
  value       = module.eks.cluster_name
}

output "cluster_endpoint" {
  description = "Endpoint for EKS control plane"
  value       = module.eks.cluster_endpoint
}

output "ecr_repository_url" {
  description = "URL of the ECR repository"
  value       = aws_ecr_repository.app_ecr_repo.repository_url
}

Execution

  1. Navigate to the terraform directory.

  2. Initialize Terraform:

    terraform init

  3. Review the plan:

    terraform plan

  4. Apply the changes to create the infrastructure (this will take 15-20 minutes):

    terraform apply --auto-approve

  5. Once complete, configure kubectl to communicate with your new cluster:

    aws eks --region $(terraform output -raw aws_region) update-kubeconfig --name $(terraform output -raw cluster_name)

  6. Verify the connection:

    kubectl get nodes
# You should see your 2 running nodes.

4. Phase 2: Setting Up Your Git Repositories

GitOps relies on Git repositories. We’ll use two:

  1. app-source-code: For the application source code and Dockerfile.

  2. gitops-manifests: For the Kubernetes manifests (Helm charts, ArgoCD applications). This is the repo ArgoCD will watch.

Action: Go to GitHub and create these two private repositories.

gitops-manifests Repository Structure

We’ll use the App of Apps pattern, which is a best practice for ArgoCD. We have a root “app” that points to other “apps”. This makes managing multiple applications/environments much easier.

Create the following structure in your gitops-manifests repo:

Generated code

.GitOps-CI-CD-with-ArgoCD-EKS-Terraform-and-Helm
└── argo-cd/
    ├── app-of-apps.yaml
    └── apps/
        └── guestbook.yaml
└── helm-charts/
    └── guestbook/
        ├── Chart.yaml
        ├── templates/
        │   ├── deployment.yaml
        │   └── service.yaml
        └── values.yaml

Populate the files:

apiVersion: v2
name: guestbook
description: A Helm chart for the Guestbook application
type: application
version: 0.1.0
appVersion: "1.0"



replicaCount: 2

image:
  repository: YOUR_ECR_REPO_URL # We will populate this later
  tag: "latest" # This will be updated by our CI pipeline
  pullPolicy: IfNotPresent

service:
  type: LoadBalancer
  port: 80



apiVersion: apps/v1
kind: Deployment
metadata:
  name: {{ .Chart.Name }}
spec:
  replicas: {{ .Values.replicaCount }}
  selector:
    matchLabels:
      app: {{ .Chart.Name }}
  template:
    metadata:
      labels:
        app: {{ .Chart.Name }}
    spec:
      containers:
        - name: {{ .Chart.Name }}
          image: "{{ .Values.image.repository }}:{{ .Values.image.tag }}"
          imagePullPolicy: {{ .Values.image.pullPolicy }}
          ports:
            - containerPort: 80
apiVersion: v1
kind: Service
metadata:
  name: {{ .Chart.Name }}-service
spec:
  selector:
    app: {{ .Chart.Name }}
  ports:
    - protocol: TCP
      port: {{ .Values.service.port }}
      targetPort: 80
  type: {{ .Values.service.type }}

Now, let’s create the ArgoCD application manifests.

This file tells ArgoCD about our guestbook application.

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: guestbook
  namespace: argocd
spec:
  project: default
  source:
    repoURL: 'YOUR_GITOPS_MANIFESTS_REPO_URL' # e.g., https://github.com/Consultantsrihari/gitops-manifests.git
    targetRevision: HEAD
    path: helm-charts/guestbook # Path to the Helm chart
    helm:
      valueFiles:
      - values.yaml
  destination:
    server: 'https://kubernetes.default.svc'
    namespace: guestbook
  syncPolicy:
    automated:
      prune: true
      selfHeal: true
    syncOptions:
    - CreateNamespace=true

This is the root application that deploys all other applications.

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: app-of-apps
  namespace: argocd
spec:
  project: default
  source:
    repoURL: 'YOUR_GITOPS_MANIFESTS_REPO_URL' # e.g., https://github.com/Consultantsrihari/gitops-manifests.git
    targetRevision: HEAD
    path: argo-cd/apps # Path to the directory containing all our app definitions
  destination:
    server: 'https://kubernetes.default.svc'
    namespace: argocd
  syncPolicy:
    automated:
      prune: true
      selfHeal: true

Action:

  1. Replace YOUR_GITOPS_MANIFESTS_REPO_URL in the two files above.

  2. Commit and push this entire structure to your gitops-manifests repository.

5. Phase 3: Installing and Configuring ArgoCD

Now we install ArgoCD into our EKS cluster.

  1. Create a namespace for ArgoCD:

    kubectl create namespace argocd

  2. Install ArgoCD using Helm:

    helm repo add argo https://argoproj.github.io/argo-helm
helm repo update
helm install argocd argo/argo-cd --namespace argocd

  3. Access the ArgoCD UI:
    For security, the API server isn’t exposed publicly by default. We’ll use port-forwarding to access it.

    kubectl port-forward svc/argocd-server -n argocd 8080:443

    Now, open https://localhost:8080 in your browser.

  4. Get the initial admin password:

    kubectl -n argocd get secret argocd-initial-admin-secret -o jsonpath="{.data.password}" | base64 -d

    Login to the UI with username admin and this password.

  5. Connect ArgoCD to your gitops-manifests repo:
    Since your repo is private, you need to give ArgoCD access. The easiest way is with a Deploy Key.

    • In the ArgoCD UI, go to Settings -> Repositories.

    • Click CONNECT REPO USING HTTPS.

    • Enter your gitops-manifests repo URL.

    • For username, enter git.

    • For password, you’ll need a GitHub Personal Access Token (PAT). Go to GitHub -> Settings -> Developer settings -> Personal access tokens -> Generate new token. Give it the repo scope. Copy the token and paste it as the password in ArgoCD.

    • Click Connect. You should see Connection Successful.

6. Phase 4: Deploying a Sample Application with Helm & ArgoCD

Now for the magic. We’ll tell ArgoCD to deploy our app-of-apps.

  1. Bootstrap the process:
    Apply the root app-of-apps.yaml manifest to your cluster. This is the only manual kubectl apply we need to do for our applications.

    # Create a local copy of the file
cat <<EOF > app-of-apps.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: app-of-apps
  namespace: argocd
spec:
  project: default
  source:
    repoURL: 'YOUR_GITOPS_MANIFESTS_REPO_URL' # Replace with your repo URL
    targetRevision: HEAD
    path: argo-cd/apps
  destination:
    server: 'https://kubernetes.default.svc'
    namespace: argocd
  syncPolicy:
    automated:
      prune: true
      selfHeal: true
EOF

# Apply it
kubectl apply -f app-of-apps.yaml

  2. Observe in ArgoCD:

    • Go to your ArgoCD UI. You will see a new application called app-of-apps.

    • Click on it. You will see that it has created another application called guestbook.

    • Initially, guestbook might be Missing and OutOfSync. Click Sync.

    • ArgoCD will now read the guestbook.yaml definition, find its Helm chart in the specified path (helm-charts/guestbook), and deploy it to the guestbook namespace in your cluster.

Your application is now deployed! However, it won’t work yet because the image URL in values.yaml is invalid. We will fix this in the CI phase.

7. Phase 5: Managing Secrets with External Secrets Operator

Hardcoding secrets is bad. We’ll use AWS Secrets Manager and the External Secrets Operator (ESO) to inject secrets securely.

  1. Create a Secret in AWS Secrets Manager:
    Let’s imagine our app needs a database password.

    aws secretsmanager create-secret --name guestbook/db-password --secret-string 'SuperSecretPassword123'

  2. Install External Secrets Operator using Helm:

    helm repo add external-secrets https://charts.external-secrets.io
helm repo update
helm install external-secrets external-secrets/external-secrets \
    -n external-secrets --create-namespace

  3. Configure IAM Role for Service Account (IRSA):
    This is the secure way to grant pods AWS permissions without using access keys.

    • We need to create an IAM OIDC provider for our cluster. Terraform has already done this for us via the EKS module.

    • Create a file iam-for-eso.tf in your terraform/ directory to create the specific role.

    terraform/iam-for-eso.tf:

    data "aws_iam_policy_document" "secret_reader_policy" {
  statement {
    actions   = ["secretsmanager:GetSecretValue", "secretsmanager:DescribeSecret"]
    resources = ["arn:aws:secretsmanager:${var.aws_region}:${data.aws_caller_identity.current.account_id}:secret:guestbook/*"]
    effect    = "Allow"
  }
}

resource "aws_iam_policy" "secret_reader_policy" {
  name        = "${var.cluster_name}-secret-reader-policy"
  description = "Allows reading specific secrets from Secrets Manager"
  policy      = data.aws_iam_policy_document.secret_reader_policy.json
}

data "aws_caller_identity" "current" {}

module "iam_assumable_role_for_sa" {
  source  = "terraform-aws-modules/iam/aws//modules/iam-assumable-role-with-oidc"
  version = "5.30.0"

  create_role                   = true
  role_name                     = "${var.cluster_name}-guestbook-sa-role"
  provider_url                  = replace(module.eks.cluster_oidc_issuer_url, "https://", "")
  role_policy_arns              = [aws_iam_policy.secret_reader_policy.arn]
  oidc_fully_qualified_subjects = ["system:serviceaccount:guestbook:guestbook-sa"] # namespace:serviceaccount-name
}

    • Run terraform apply –auto-approve again to create this IAM role.

    • Add an output to your outputs.tf to easily get the role ARN:

      output "guestbook_sa_role_arn" {
  description = "ARN of the IAM role for the guestbook service account"
  value       = module.iam_assumable_role_for_sa.iam_role_arn
}

    • Run terraform apply one more time

  4. Create Kubernetes resources in your GitOps repo:
    Add these files to your gitops-manifests repo inside helm-charts/guestbook/templates/.

    helm-charts/guestbook/templates/secret-store.yaml

    apiVersion: external-secrets.io/v1beta1
kind: SecretStore
metadata:
  name: aws-secret-store
spec:
  provider:
    aws:
      service: SecretsManager
      region: {{ .Values.aws.region | default "us-east-1" }}
      role: {{ .Values.aws.serviceAccountRoleArn }}

    helm-charts/guestbook/templates/external-secret.yaml

    apiVersion: external-secrets.io/v1beta1
kind: ExternalSecret
metadata:
  name: db-password-secret
spec:
  secretStoreRef:
    name: aws-secret-store
    kind: SecretStore
  target:
    name: db-credentials # Name of the k8s secret that will be created
    creationPolicy: Owner
  data:
  - secretKey: password
    remoteRef:
      key: guestbook/db-password

    helm-charts/guestbook/templates/service-account.yaml

    apiVersion: v1
kind: ServiceAccount
metadata:
  name: guestbook-sa
  annotations:
    # This annotation links the k8s SA to the IAM Role
    eks.amazonaws.com/role-arn: {{ .Values.aws.serviceAccountRoleArn }}

  5. Update values.yaml and deployment.yaml:

    • helm-charts/guestbook/values.yaml:

      # ... existing values ...
aws:
  region: "us-east-1" # Your AWS Region
  serviceAccountRoleArn: "YOUR_IAM_ROLE_ARN" # The output from terraform

    • helm-charts/guestbook/templates/deployment.yaml: Add serviceAccountName and mount the secret.

      # ...
spec:
  # ...
  template:
    # ...
    spec:
      serviceAccountName: guestbook-sa # Use our new service account
      containers:
        - name: {{ .Chart.Name }}
          # ...
          env:
            - name: DB_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: db-credentials # The k8s secret created by ESO
                  key: password


Action:

  1. Get the IAM Role ARN: terraform output -raw guestbook_sa_role_arn

  2. Update values.yaml with this ARN.

  3. Commit and push all new files and changes to your gitops-manifests repo.

  4. ArgoCD will sync automatically, creating the Service Account, SecretStore, and ExternalSecret. ESO will then create the final Kubernetes Secret named db-credentials. Your pod now has the password available as an environment variable.

8. Bonus: Canary Deployments with Argo Rollouts

Argo Rollouts is a progressive delivery controller that provides advanced deployment strategies like canary and blue-green.

  1. Install Argo Rollouts Controller:

    kubectl create namespace argo-rollouts
kubectl apply -n argo-rollouts -f https://github.com/argoproj/argo-rollouts/releases/latest/download/install.yaml

  2. Change Deployment to Rollout:
    In your gitops-manifests repo, rename helm-charts/guestbook/templates/deployment.yaml to helm-charts/guestbook/templates/rollout.yaml and change its content.

    helm-charts/guestbook/templates/rollout.yaml

    apiVersion: argoproj.io/v1alpha1
kind: Rollout # Changed from Deployment
metadata:
  name: {{ .Chart.Name }}
spec:
  replicas: {{ .Values.replicaCount }}
  strategy:
    canary: # Define the canary strategy
      steps:
      - setWeight: 20 # Send 20% of traffic to the new version
      - pause: { duration: 30s } # Pause for 30 seconds to observe
      - setWeight: 50 # Send 50% traffic
      - pause: { duration: 30s }
      # The rollout will be fully promoted after the last step
  selector:
    matchLabels:
      app: {{ .Chart.Name }}
  template: # The pod template is now nested under template
    metadata:
      labels:
        app: {{ .Chart.Name }}
    spec:
      serviceAccountName: guestbook-sa
      containers:
        - name: {{ .Chart.Name }}
          image: "{{ .Values.image.repository }}:{{ .Values.image.tag }}"
          imagePullPolicy: {{ .Values.image.pullPolicy }}
          ports:
            - containerPort: 80
          env:
            - name: DB_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: db-credentials
                  key: password

  3. Delete the old deployment.yaml and commit the new rollout.yaml. ArgoCD will sync and replace the Deployment with a Rollout object.

Now, whenever you update the image tag, Argo Rollouts will manage the update according to your canary strategy instead of doing a standard rolling update. You can observe the process with the kubectl plugin: kubectl argo rollouts get rollout guestbook -n guestbook –watch.

9. Putting It All Together: The CI Pipeline (GitHub Actions)

This pipeline will live in your app-source-code repository. It will build and push the Docker image, then update the gitops-manifests repo to trigger the deployment.

  1. Create a Sample Application:
    In your app-source-code repo, create a simple web app.

    app/main.py (A simple Flask app)

    from flask import Flask
import os

app = Flask(__name__)

@app.route('/')
def hello():
    db_pass = os.environ.get("DB_PASSWORD", "Not Found")
    # In a real app, you'd use this password to connect to a DB.
    # Here we just display a part of it for demonstration.
    return f"<h1>Hello from the Guestbook App!</h1><p>DB Password starts with: {db_pass[:3]}...</p>"

if __name__ == "__main__":
    app.run(host='0.0.0.0', port=80)

    app/requirements.txt

    Flask==2.2.2

    Dockerfile

    FROM python:3.9-slim

WORKDIR /app
COPY app/requirements.txt .
RUN pip install --no-cache-dir -r requirements.txt
COPY app/ .

CMD ["python", "main.py"]

  2. Create the GitHub Actions Workflow:
    In your app-source-code repo, create .github/workflows/ci-cd.yml.

    name: Build, Push, and Deploy

on:
  push:
    branches:
      - main

jobs:
  build-and-deploy:
    runs-on: ubuntu-latest
    permissions:
      id-token: write # Required for AWS OIDC authentication
      contents: read

    steps:
      - name: Checkout App Source Code
        uses: actions/checkout@v3

      - name: Configure AWS Credentials
        uses: aws-actions/configure-aws-credentials@v2
        with:
          role-to-assume: ${{ secrets.AWS_IAM_ROLE_TO_ASSUME }} # IAM Role for GitHub Actions
          aws-region: ${{ secrets.AWS_REGION }}

      - name: Login to Amazon ECR
        id: login-ecr
        uses: aws-actions/amazon-ecr-login@v1

      - name: Build, tag, and push image to Amazon ECR
        env:
          ECR_REGISTRY: ${{ steps.login-ecr.outputs.registry }}
          ECR_REPOSITORY: ${{ secrets.ECR_REPOSITORY_NAME }} # e.g., guestbook-repo
          IMAGE_TAG: ${{ github.sha }}
        run: |
          docker build -t $ECR_REGISTRY/$ECR_REPOSITORY:$IMAGE_TAG .
          docker push $ECR_REGISTRY/$ECR_REPOSITORY:$IMAGE_TAG

      - name: Checkout Manifests Repo
        uses: actions/checkout@v3
        with:
          repository: Consultantsrihari/gitops-manifests # Your manifests repo
          token: ${{ secrets.GITOPS_PAT }} # The PAT for the manifests repo
          path: 'gitops-manifests'

      - name: Update Helm values file
        uses: mikefarah/yq@v4.30.8
        with:
          cmd: |
            yq e '.image.tag = "${{ github.sha }}"' -i 'gitops-manifests/helm-charts/guestbook/values.yaml'
            yq e '.image.repository = "${{ steps.login-ecr.outputs.registry }}/${{ secrets.ECR_REPOSITORY_NAME }}"' -i 'gitops-manifests/helm-charts/guestbook/values.yaml'

      - name: Commit and push changes
        run: |
          cd gitops-manifests
          git config --global user.name "techcareerhub"
          git config --global user.email "techcareerhubs@gmail.com"
          git commit -am "Update image tag to ${{ github.sha }}"
          git push

  3. Configure GitHub Actions Secrets and IAM:

    • IAM Role for GitHub Actions: You need to create an IAM role that GitHub Actions can assume. This is another IRSA-like setup, but for GitHub. Follow the official AWS guide to create this role. It needs permissions to push to your ECR repository.

    • GitHub Secrets: In your app-source-code repository settings (Settings -> Secrets and variables -> Actions), add the following secrets:

      • AWS_REGION: e.g., us-east-1

      • AWS_IAM_ROLE_TO_ASSUME: The ARN of the IAM role you just created for GitHub Actions.

      • ECR_REPOSITORY_NAME: The name of your ECR repo (e.g., guestbook-repo).

      • GITOPS_PAT: The GitHub Personal Access Token you created earlier, which has repo access to your gitops-manifests repository.

Action:

  1. Push the sample Flask app and Dockerfile to your app-source-code repo.

  2. Create the IAM Role for GitHub Actions.

  3. Add the required secrets to your GitHub repo.

  4. Push the ci-cd.yml workflow file.

Now, every push to the main branch of app-source-code will trigger the pipeline, which in turn will trigger ArgoCD to deploy the new version via the canary strategy.

10. Tearing Down the Infrastructure

To avoid ongoing AWS costs, destroy all the resources you created.

  1. Navigate to your terraform/ directory.

  2. Run the destroy command:

    terraform destroy --auto-approve

This will delete the EKS cluster, VPC, IAM roles, and ECR repository. Your GitHub repositories and secrets will remain.

For more information about Job Notifications, Open-source Projects, DevOps and Cloud project, please stay tuned TechCareerHubs official website.

argocdAWSCI/CDdevopsDockerKubernetsTerraform
⁣

Tech Career Hubs

At TechCareerHubs, we aim to bridge the gap between talent and opportunity. Our mission is to provide accurate, timely, and reliable job notifications while keeping you informed about the latest advancements in technology and career-building courses.

🔴Related Post

Linux Top 30 Interview Questions and Answers-2025

Complete DSA Roadmap with Free Resources – Step by Step Guide 2025

Project 2: End-to-End DevOps Automation for a Scalable and Secure AI Chatbot

Project 1: AI-Powered Shell Script Website Monitor

Leave a Comment
